Descripción
12″,1000/2000w,96dB,41Hz,41-?1500Hz,100x25mm,Copper, 8 ohm
Specifications
Nominal diameter 320 mm (12.0 in)
Nominal impedance 8 O
Minimum impedance 6.5 O
Nominal power handling * 1000 W
Continuous power handling * 2000 W
Sensitivity (1W/1m) * 96.0 dB
Frequency range 40 1500 Hz
Voice coil diameter 100 mm (4.0 in)
Winding material Copper
Former material Glass Fibre
Winding depth 25 mm (1.0 in)
Magnetic gap depth 11 mm (0.43 in)
Flux density 1.1 T
Design
Surround shape Triple Roll
Cone shape Exponential
Magnet material Neodymium Ring
Spider Double Silicone
Pole design T-Pole
Woofer cone treatment TWP Waterproof Both Sides
Recommended enclosure 40.0 dm3 (1.41 ft3)
Recommended tuning 50 Hz
Parameters *
Fs 41 Hz
Re 5.1 O
Qes 0.24
Qms 3.9
Qts 0.22
Vas 51.0 dm3 (1.8 ft3)
Sd 531.0 cm2 (82.0 in2)
?0 1.45 %
Xmax 10.0 mm
Xvar 10.0 mm
Mms 117 g
Bl 25.6 Txm
Le 1.9 mH
EBP 170 Hz
Mounting And Shipping Info
Overall diameter 320 mm (12.6 in)
Bolt circle diameter 300 mm (11.8 in)
Baffle cutout diameter 280.0 mm (11.0 in)
Depth 143 mm (5.63 in)
Flange and gasket thickness 12 mm (0.47 in)
Air volume occupied by driver 4.0 dm3 (0.14 ft3)
Net weight 8.0 kg (17.6 lb)
Shipping units 1
Shipping weight 8.6 kg (18.9 lb)
Shipping box 340x340x170 mm (13.4×13.4×6.7 in)
Service Kit
RCK12NBX1008
Marca: BYC
Codigo: 3009332
