Descripción
10″,350/700w,100dB,76Hz,80-?4000Hz,76mm,Aluminum, 8 ohm
Specifications
Nominal diameter 250 mm (10.0 in)
Nominal impedance 8 O
Minimum impedance 7.2 O
Nominal power handling * 350 W
Continuous power handling * 700 W
Sensitivity (1W/1m) * 100.0 dB
Frequency range 80 4000 Hz
Voice coil diameter 76 mm (3.0 in)
Winding material Aluminium
Former material Glass Fibre
Winding depth 11 mm (0.43 in)
Magnetic gap depth 8 mm (0.31 in)
Flux density 1.45 T
Design
Surround shape Double Roll
Cone shape Exponential
Magnet material Ferrite
Spider Single
Pole design T-Pole
Woofer cone treatment None
Parameters *
Fs 76 Hz
Re 5.8 O
Qes 0.22
Qms 4.8
Qts 0.21
Vas 20.0 dm3 (0.71 ft3)
Sd 320.0 cm2 (49.1 in2)
?0 3.9 %
Xmax 1.5 mm
Xvar 4.5 mm
Mms 31 g
Bl 19.6 Txm
Le 1.2 mH
EBP 345 Hz
Mounting And Shipping Info
Overall diameter 262 mm (10.3 in)
Bolt circle diameter 245 mm (9.6 in)
Baffle cutout diameter 230.0 mm (8.8 in)
Depth 124 mm (4.9 in)
Flange and gasket thickness 14 mm (0.55 in)
Air volume occupied by driver 2.6 dm3 (0.09 ft3)
Net weight 7.3 kg (16.1 lb)
Shipping weight 7.9 kg (17.4 lb)
Shipping box 320x320x160 mm (12x12x6.3 in)
Service Kit
RCK010MD268
Marca: BYC
Codigo: 3001447
