PARLANTE 6.5″ WOOFERS 150/300W. 6NDL38 BYC 3009318

6.5″,150/300w,92dB,72Hz,70-­?6000Hz,38mm,Copper, 8 ohm

PRODUCTOS VOLVER
Parlantes /B&C Speakers /Parlantes Neodymium /Woofers / Midr

Descripción

6.5″,150/300w,92dB,72Hz,70-­?6000Hz,38mm,Copper, 8 ohm

PRODUCTOS VOLVER
Parlantes /B&C Speakers /Parlantes Neodymium /Woofers / Midrange 6″ / 6NDL38

CARACTERÍSTICASDATOS TÉCNICOSDESCARGAS
Specifications
Nominal diameter 170 mm (6.5 in)
Nominal impedance 8 O
Minimum impedance 6.0 O
Nominal power handling * 150 W
Continuous power handling * 300 W
Sensitivity (1W/1m) * 92.0 dB
Frequency range 70 – 6000 Hz
Voice coil diameter 38 mm (1.5 in)
Winding material Copper
Former material Kapton
Winding depth 12 mm (0.5 in)
Magnetic gap depth 6 mm (0.25 in)
Flux density 1.15 T
Design
Surround shape Roll
Cone shape Exponential
Magnet material Neodymium Ring
Spider Single
Pole design T-Pole
Woofer cone treatment WP Waterproof Front Side
Recommended enclosure 9.0 dm3 (0.32 ft3)
Recommended tuning 62 Hz
Parameters *
Fs 72 Hz
Re 5.2 O
Qes 0.44
Qms 11.5
Qts 0.42
Vas 7.0 dm3 (0.25 ft3)
Sd 132.0 cm2 (20.5 in2)
?0 0.6 %
Xmax 6.0 mm
Xvar 5.5 mm
Mms 17 g
Bl 9.5 Txm
Le 0.6 mH
EBP 163 Hz
Mounting And Shipping Info
Overall diameter 187 mm (7.4 in)
Bolt circle diameter 172 mm (6.7 in)
Baffle cutout diameter 145.0 mm (5.7 in)
Depth 85 mm (3.3 in)
Flange and gasket thickness 11 mm (0.4 in)
Air volume occupied by driver 0.63 dm3 (0.02 ft3)
Net weight 1.2 kg (2.6 lb)
Shipping units 1
Shipping weight 1.45 kg (3.2 lb)
Shipping box 221x214x130 mm (8.7×8.4×5.1 in)
Service Kit
RCK06NDL388

Marca: BYC
Codigo: 3009318

Información adicional

Modelo

6NDL38

CodInt

30147

Cod

3009318

Marca

BYC

Ean

20301477
