Descripción
2.0″,110/220w,107.5dB,500Hz-?18kHz,75mm(3.0″),Aluminum, 8, 16 ohm
Specifications *
Throat diameter 50 mm (2.0 in)
Nominal impedance 8 O
Minimum impedance 8.4 O
Nominal power handling * 110 W
Continuous power handling * 220 W
Sensitivity (1W/1m) * 107.5 dB
Frequency range 1 18 kHz
Recommended crossover * 1.0 kHz
Voice coil diameter 75 mm (3.0 in)
Winding material Aluminium
Inductance 0.14 mH
Diaphragm material Titanium
Flux density 1.6 T
Magnet material Ferrite
Mounting And Shipping Info
Four M6 holes 90° on 102 mm (4 in) diameter
Overall diameter 156 mm (6.1 in)
Depth 68 mm (2.68 in)
Net weight 4.1 kg (9.0 lb)
Shipping units 2
Shipping weight 8.8 kg (19.3 lb)
Shipping box 210x210x190 mm (8.3×8.3×7.5 in)
Replacement Diaphragm
MMD064TN8
Modelo: DE64TN
Marca: BYC
Codigo: 3009360
